Hunter Engineering HD Four-Post Alignment Lift (L494HD)

Hunter Engineering

HD Four-Post Alignment Lift (L494HD)

four-post-lifts

A heavy-duty four-post truck lift with 35,000 lb capacity and 300 in. alignment wheelbase capability on galvanized runways. It arrives alignment-ready with turnplate pockets and slipplates, built for commercial and fleet work. Tell us about your facility so we can review installation needs and options with you.

Finish

Choose a factory finish to add this product to your project.

Finish availability can change by model, series and production run. TAG confirms current factory finish availability with the manufacturer before ordering.

Key specifications

Capacity
35,000 lb
Loaded lifting speed
82 seconds at half capacity
Post height
91.5 in.
Stack height
11.88 in.
Outside width
179.5 in.
Inside width
44 in.
Specifications

Nothing is purchased online. TAG confirms configuration with you.

Choose a factory finish above before adding this product to your project.

Not in your project yet

Configure This ModelRequest Consultation

Fit & requirements

Review the space and utility needs for this model with TAG before ordering.

Capacity
35,000 lb
Electrical
208-230 VAC, single phase, 26 A
Lift air supply
90-150 psi
Jack air supply
115 psi minimum
Minimum concrete
6 in. thick, 3,000 psi
Maximum floor variation
3 in. between any two posts
Overall length
420 in.

What TAG confirms with you

  • Slab thickness, age and condition where the lift will be anchored
  • Bay width, drive-through length and ceiling height at the highest point
  • Overhead obstructions: doors, lighting, ductwork and sprinkler heads
  • Vehicles you lift most often, including the heaviest and longest
  • Electrical service available at the bay and who runs the final connection
Ask TAG about this model

Capacity & Dimensions

Model
L494HD heavy-duty four-post lift
Capacity
35,000 lb
Electrical
208-230 VAC, single phase, 26 A
Lift air supply
90-150 psi
Jack air supply
115 psi minimum
Minimum concrete
6 in. thick, 3,000 psi
Maximum floor variation
3 in. between any two posts
Overall length
420 in.
Outside width
179.5 in.
Inside width
44 in.
Post height
91.5 in.
Runway width
30 in., galvanized
Stack height
11.88 in.
Maximum service wheelbase
320 in.
Maximum two-wheel alignment wheelbase
300 in.
Four-wheel alignment wheelbase range
88-158 in.
Lock positions
Seven
Loaded lifting speed
82 seconds at half capacity
Loaded lowering speed
70 seconds at half capacity
Standard
Built-in slipplates and turnplate pockets
Options
One or two 20,000 lb jacks, Fully Integrated Alignment (FIA)/PowerSlide® automation, AlignLights, 41 in. approach ramp extensions for high floor slopes or low-clearance vehicles

Configure this HD Four-Post Alignment Lift (L494HD)

Add the machine to your TAG Project and the configuration steps — quantity, installation, training and site readiness — open right here. Nothing is priced or ordered online.

Compatible accessories

TAG confirms final fit and configuration before purchase.

Optional accessory · 1

Fits across the range

Manufacturer-listed for the Hunter alignment lift and rack range rather than for one exact model. TAG confirms final fit and configuration before purchase.

Build out this work area

Related Equipment to Review

Related equipment to review for this work area.

Final configuration is confirmed before purchase.

How TAG can help

Ask TAG about delivery, installation, training and service for this equipment. Your quote will state what is included.

  • Site review

    TAG reviews equipment dimensions, clearances, slab, utilities and site requirements with you.

  • Delivery & installation

    Plan delivery and installation with TAG. Your quote will state what is included.

  • Training

    Ask TAG about training for your team and the equipment you choose.

  • Service & calibration

    Contact TAG to confirm service options for this model in your area.

Next step

Ready to scope this model into your shop?

TAG will confirm configuration, installation requirements, training and service coverage for your facility.
